| Part Number | Description | Quantity | Item | Designation/Location |
|---|---|---|---|---|
| 011-A5-105 | 1µF 50V E CAP | 1 | 30 | C41 |
| 011-A5-106 | 10µF 50V E CAP | 2 | 53 | C44,45 |
| 011-A5-226 | 22µF 25V E CAP | 2 | 28 | C34,35 |
| 011-A5-475 | 50V E CAP 4.7 µF | 1 | 59 | C11 |
| 011-A8-107 | 100µF 25V E CAP | 10 | 29 | C17,21-23,25,7,26,31,39,40 |
| 011-B5-336 | 33µF 25V E CAP | 2 | 25 | C5,37 |
| 031-A3-220 | 22PF 500V S CAP | 1 | 27 | C33 |
| 031-A3-500 | 50PF 500V S CAP | 1 | 26 | C1 |
| 031-A3-500 | 50PF 500V S CAP | 1 | 54 | C43 |
| 041-A4-103 | .01µF 63V F CAP | 3 | 31 | C47,32,46 |
| 110-22-103 | 10K 1/4W 5% CF RES | 7 | 8 | R40,61,98,118,27,41,42 |
| 110-22-104 | 100K 1/4W 5% CF RES | 7 | 12 | R53,54,71,72,105,119,120 |
| 110-22-105 | 1M 1/4W 5% CF RES | 2 | 3 | R4,12 |
| 110-22-152 | 1.5K 1/4W 5% CF RES | 1 | 18 | R107 |
| 110-22-154 | 150K 1/4W 5% CF RES | 1 | 19 | R110 |
| 110-22-221 | 220 1/4W 5% CF RES | 3 | 1 | R1,2,84 |
| 110-22-222 | 2.2K 1/4W 5% CF RES | 3 | 4 | R106,114,116 |
| 110-22-223 | 22K 1/4W 5% CF RES | 1 | 10 | R47 |
| 110-22-332 | 3.3K 1/4W 5% CF RES | 2 | 2 | R3,11 |
| 110-22-391 | 390 1/4W 5% CR FES | 2 | 16 | R80,95 |
| 110-22-392 | 3.9K 1/4W 5% CF RES | 2 | 9 | R29,30 |
| 110-22-472 | 4.7K 1/4W 5% CF RES | 2 | 13 | R85,99 |
| 110-22-473 | 47K 1/4W 5% CF RES | 3 | 15 | R97,108,109 |
| 110-22-474 | 470K 1/4W 5% CF RES | 1 | 20 | R111 |
| 110-22-511 | 510 1/4W 5% CF RES | 2 | 6 | R18,22 |
| 110-22-753 | 75K 1/4W 5% CF RES | 1 | 14 | R104 |
| 120-20-10S | 10K 1/4W 1% MF RES | 2 | 5 | R9,10 |
| 120-20-33N | 3.32K 1/4W 1% MF RES | 1 | 11 | R48 |
| 120-20-51N | 5.11K 1/4W 1% MF RES | 1 | 7 | R19 |
| 13M-33-103 | 10K V TRIM | 2 | 21 | R17,21 |
| 13M-33-203 | 20K V TRIM | 1 | 23 | R96 |
| 13M-33-504 | 500K V TRIM | 1 | 22 | R82 |
| 200-A0-000 | 1N4148 DIODE | 2 | 33 | D11,12 |
| 204-A0-002 | 1N4733A DIODE | 2 | 35 | D7,8 |
| 204-A0-004 | 1N4737A DIODE | 2 | 34 | D3,4 |
| 210-A0-002 | GES5816 TRANSISTOR | 2 | 37 | Q7,8 |
| 220-A0-000 | P1086 FET | 2 | 36 | Q1,3 |
| 230-A0-000 | NE5532N IC | 1 | 39 | U1 |
| 230-A0-001 | NE5533N IC | 1 | 38 | U4 |
| 231-A0-024 | 4052 IC | 1 | 42 | U9 |
| 231-A0-028 | 4081 IC | 1 | 40 | U6 |
| 231-A0-036 | 4070 IC | 2 | 41 | U7,8 |
| 280-A0-000 | LM394CH TRANSISTOR | 1 | 48 | A2 |
| 300-A0-000 | INDUCTOR BALUN | 1 | 55 | L1 |
| 369-A0-000 | SWITCH DIP 4POS | 1 | 43 | SW |
| 407-D0-010 | PLAY AMP PCB CTR 100 | 1 | 51 | |
| 410-A0-001 | 8 PIN DIP SOCKET | 1 | 44 | U1 |
| 410-A0-002 | 14 PIN DIP SOCKET | 4 | 45 | U6,7,8,4 |
| 410-A0-003 | 16 PIN DIP SOCKET | 1 | 46 | U9 |
| 416-A0-015 | 6 PIN HEADER | 1 | 47 | P1 |
| 418-A0-004 | 9 PIN FEMALE SUB D D | 1 | 49 | J1 |
| 41G-A0-001 | CONN HARDWARE | 1 | 52 | |
| 5AB-A0-007 | BOARD PULLER | 2 | 50 | |
| 601-20-440 | NUT HEX 4-40 STEEL PLATE | 2 | 57 | |
| 60C-11-400 | L. WASHER IT. £4 | 2 | 56 | |
| 621-05-440 | PAN HD. PHL. 4-40 x 5/16 | 2 | 58 |
